AE APE-Power Luminex 5kWh LiFePO₄ Home Battery | 51.2V 200Ah

AE APE-Power Luminex 5kWh

Engineered for homeowners who need a dependable, safe, and long-lasting battery system. Using LiFePO₄ chemistry and an intelligent BMS, Luminex delivers long cycle life — ≥80% capacity retention at 25°C with 80% depth of discharge and stable performance under daily cycling. Perfect for coupling with rooftop solar to store excess generation, supply overnight loads, or act as a compact backup system during outages. Simple to install and monitor with built-in LED indicators. Supports Bluetooth & Wi-Fi connectivity with mobile app for convenient system monitoring. Australian warranty and local support included.

Specifications & Features:

• 51.2V nominal / 100Ah — 5.12kWh usable energy
• LiFePO₄ cells — safer, longer cycle life
• Built-in BMS with cell balancing, over-charge and over-discharge protection
• Supports recharging via solar panels, wall outlets, or generators, maximizing solar energy usage, reducing electricity costs, providing immediate power during outages, and lowering carbon footprint
• Compact stand mount design
• Scalable — easily expand your system by connecting additional units
• Ideal for home solar storage, backup power, and peak shaving

Specifications:

• Model: Luminex 5kWh
• Battery Type: LiFePO₄ (LFP)
• Nominal Voltage: 51.2 V
• Rated Capacity: 100 Ah
• Rated Energy: 51.2 × 100 = 5120 Wh = 5.12 kWh
• Usable DoD: 80%
• Max Charge Current: 100 A
• Max Discharge Current: 100 A
• Cycle Life: ≥6000–8000 cycles @ 80% DoD
• Inverter：5kw
• Configuration：16S1P
• Dimension：W600*L400*T200mm
• Weight：52kg
• Working Temperature: 0°C ~ +55°C
• Storage Temperature: -20°C ~ +60°C
• Communica tion: Bluetooth + Wi-Fi, App monitoring
• Mounting: Wall-mount or floor stand

Accessorices:

• AE APE-Power Luminex 5kWh
• Positive cable
• Negative cable
• Specification
• Protocal Cable
• Wrench
